Product Description
| TECHNICAL DATA | CONQUEST 515 |
| Strokes | |
| Y: mm. 1990 | |
| Z: mm. 430 | |
| Y: mm. 1990 | |
| Z: mm. 430 | |
| Y: mm. 2590 | |
| Z: mm. 430 | |
| Working field | mm. 3170 x 1600 |
| Max thickness for panel feeding | mm. 250/500/700/1000 |
| Vectorial speed | 85 mt/min |
| Linear speed | 60 mt/min |
| Spindle rotation | 500-20000 rpm |
| Spindler power | Kw. 6,6 / 7,5 / 11 |
| Tool chuck | ISO 30 – HSK F63 |
| Inverter power | Kw. 11 / 15 |
| Vacuum pump capacity | 100 / 180 / 250 mc/h |
| Standard numerical control | OSAI serie 10 with PC |
| Automatic tool changer | 12 positions |
| INSTALLATION DATA | CONQUEST 515 |
| Air-working pressure | 7 bar |
| Air-circuit connetion coupling | G 3/8″ |
| Extraction socket | mm. 160 |
| Air consumption for extraction | 1300 mc/h |
| DISPATCH DATA | CONQUEST 515 |
| Weight | 4150 Kg. |
| Dispatch dimensions | mm. 5400 x 2330 x 2500 |
